• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Number of Teeth	16
Chain Pitch (in)	1.5 in
Material	Steel, Hardened Teeth
Product Type	Bushed Roller Chain Sprocket
Min Bore (in)	0.75 in
Pitch Diameter (in)	7.689 in
Max Bore (in)	2.6875 in
Chain Used	No. 120, 1-1/2 in. Pitch ANSI Chain
Bushing Used	Split Taper
Outside Diameter (in)	8.441 in
Overall Length (in)	2.828125 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289722990
Weight	12.66 LB
Packaged Length	10.60 IN
Packaged Width	10.60 IN
Packaged Height	2.60 IN
HTC	8483.90.1050
Country of Origin	China
