• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Number of Teeth	15
Bushing Used	Split Taper
Chain Used	No. 120, 1-1/2 in. Pitch ANSI Chain
Max Bore (in)	2.6875 in
Pitch Diameter (in)	7.215 in
Chain Pitch (in)	1.5 in
Product Type	Bushed Roller Chain Sprocket
Material	Steel, Hardened Teeth
Min Bore (in)	0.75 in
Bore Type	Bushed Bore
Outside Diameter (in)	7.957 in
Overall Length (in)	2.828125 in
Number of Strands/Width	1
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289216581
Weight	10.76 LB
Packaged Length	8.50 IN
Packaged Width	8.60 IN
Packaged Height	2.40 IN
HTC	8483.90.1050
Country of Origin	China
