• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Max Bore (in)	3.75 in
Chain Used	No. 100, 1-1/4 in. Pitch ANSI Chain
Bushing Used	Split Taper
Min Bore (in)	1.125 in
Pitch Diameter (in)	11.164 in
Product Type	Bushed Roller Chain Sprocket
Number of Teeth	28
Chain Pitch (in)	1.25 in
Material	Steel, Hardened Teeth
Bore Type	Bushed Bore
Overall Length (in)	3.219375 in
Outside Diameter (in)	11.844 in
Number of Strands/Width	1
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Maximum Bore (mm)	95 mm
Minimum Bore (mm)	28 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289722976
Weight	20.22 LB
Packaged Length	11.88 IN
Packaged Width	11.88 IN
Packaged Height	2.25 IN
HTC	8483.90.1050
Country of Origin	China
