• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Pitch Diameter (in)	9.973 in
Bushing Used	Split Taper
Chain Used	No. 100, 1-1/4 in. Pitch ANSI Chain
Max Bore (in)	3.75 in
Product Type	Bushed Roller Chain Sprocket
Chain Pitch (in)	1.25 in
Material	Steel
Min Bore (in)	1.125 in
Number of Teeth	25
Bore Type	Bushed Bore
Outside Diameter (in)	10.645 in
Overall Length (in)	3.219375 in
Number of Strands/Width	1
Tooth Width (in)	0.692 in
Hub Diameter (in)	5.375 in
Length Through Bore (in)	2.875 in
Maximum Bore (in)	3.75 in
Minimum Bore (mm)	28 mm
Maximum Bore (mm)	95 mm
Hub Projection (in)	2.188 in
Pitch Type	Single
Hardened Teeth	Yes
Number of Hubs	1
Overall Width (in)	3.15625 in

General Specifications

UPC	662289770199
Weight	17.41 LB
Packaged Length	10.80 IN
Packaged Width	10.90 IN
Packaged Height	2.60 IN
HTC	8483.90.1050
Country of Origin	China
