• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Pitch Diameter (in)	9.18 in
Number of Teeth	23
Bushing Used	Split Taper
Chain Used	No. 100, 1-1/4 in. Pitch ANSI Chain
Chain Pitch (in)	1.25 in
Max Bore (in)	2.6875 in
Material	Steel, Hardened Teeth
Min Bore (in)	0.75 in
Product Type	Bushed Roller Chain Sprocket
Outside Diameter (in)	9.844 in
Overall Length (in)	2.828125 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289166428
Weight	14.04 LB
Packaged Length	10.00 IN
Packaged Width	10.00 IN
Packaged Height	1.70 IN
HTC	8483.90.1050
Country of Origin	China
