• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Bushing Used	Split Taper
Chain Used	No. 100, 1-1/4 in. Pitch ANSI Chain
Product Type	Bushed Roller Chain Sprocket
Number of Teeth	15
Max Bore (in)	2.6875 in
Min Bore (in)	0.75 in
Material	Steel, Hardened Teeth
Chain Pitch (in)	1.25 in
Pitch Diameter (in)	6.012 in
Outside Diameter (in)	6.631 in
Overall Length (in)	2.828125 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289116386
Weight	6.85 LB
Packaged Length	7.30 IN
Packaged Width	7.20 IN
Packaged Height	2.10 IN
HTC	8483.90.1050
Country of Origin	China
