• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Used	No. 80, 1 in. Pitch ANSI Chain
Bushing Used	Split Taper
Material	Steel
Number of Teeth	19
Max Bore (in)	2.6875 in
Chain Pitch (in)	1 in
Pitch Diameter (in)	6.076 in
Product Type	Bushed Roller Chain Sprocket
Min Bore (in)	0.75 in
Bore Type	Bushed Bore
Overall Length (in)	3.28125 in
Outside Diameter (in)	6.593 in
Number of Strands/Width	2
Length Through Bore (in)	2.5 in
Tooth Width (in)	0.575 in
Hub Diameter (in)	4.125 in
Hub Projection (in)	0.844 in
Hardened Teeth	Yes
Pitch Type	Single
Overall Width (in)	3.281 in

General Specifications

UPC	662289228546
Weight	10.66 LB
Packaged Length	7.00 IN
Packaged Width	7.10 IN
Packaged Height	2.50 IN
HTC	8483.90.1050
Country of Origin	China
