• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Pitch (in)	0.625 in
Product Type	Bushed Roller Chain Sprocket
Material	Steel
Number of Teeth	24
Pitch Diameter (in)	4.788 in
Min Bore (in)	0.5 in
Max Bore (in)	1.75 in
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Bushing Used	Split Taper
Bore Type	Bushed Bore
Length Through Bore (in)	1.9375 in
Overall Length (in)	2.46875 in
Hub Type	Bushed
Tooth Width (in)	0.343 in
Sprocket Material	Steel
Hub Diameter (in)	3 in
Outside Diameter (in)	5.12 in
Number of Strands/Width	2
Pitch Type	Single
Hardened Teeth	Yes
Min Bushing Bore (in)	0.5 in
Max Bushing Bore (in)	1.75 in

General Specifications

UPC	662289258406
Weight	6.06 LB
Packaged Length	6.40 IN
Packaged Width	6.20 IN
Packaged Height	2.60 IN
HTC	8483.90.1050
Country of Origin	China
