• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Max Bore (in)	1.75 in
Number of Teeth	23
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Min Bore (in)	0.5 in
Product Type	Bushed Roller Chain Sprocket
Chain Pitch (in)	0.625 in
Bushing Used	Split Taper
Pitch Diameter (in)	4.59 in
Material	Steel
Overall Length (in)	2.46875 in
Tooth Width (in)	0.343 in
Sprocket Material	Steel
Outside Diameter (in)	4.922 in
Length Through Bore (in)	1.9375 in
Bore Type	Bushed Bore
Hub Diameter (in)	3 in
Hub Type	Bushed
Number of Strands/Width	2
Hardened Teeth	Yes
Pitch Type	Single
Max Bushing Bore (in)	1.75 in
Min Bushing Bore (in)	0.5 in

General Specifications

UPC	662289128471
Weight	4.96 LB
Packaged Length	5.06 IN
Packaged Width	5.06 IN
Packaged Height	1.88 IN
HTC	8483.90.1050
Country of Origin	China
