• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Max Bore (in)	1.75 in
Pitch Diameter (in)	4.194 in
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Bushing Used	Split Taper
Number of Teeth	21
Chain Pitch (in)	0.625 in
Material	Steel
Min Bore (in)	0.5 in
Product Type	Bushed Roller Chain Sprocket
Hub Diameter (in)	3 in
Bore Type	Bushed Bore
Outside Diameter (in)	4.522 in
Overall Length (in)	2.46875 in
Tooth Width (in)	0.343 in
Hub Type	Bushed
Sprocket Material	Steel
Length Through Bore (in)	1.9375 in
Number of Strands/Width	2
Pitch Type	Single
Hardened Teeth	Yes
Max Bushing Bore (in)	1.75 in
Min Bushing Bore (in)	0.5 in

General Specifications

UPC	662289208449
Weight	3.80 LB
Packaged Length	5.06 IN
Packaged Width	5.06 IN
Packaged Height	1.88 IN
HTC	8483.90.1050
Country of Origin	China
