• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Material	Steel
Min Bore (in)	0.375 in
Chain Pitch (in)	0.5 in
Max Bore (in)	1.5 in
Product Type	Bushed Roller Chain Sprocket
Pitch Diameter (in)	3.0378 in
Number of Teeth	19
Bushing Used	Split Taper
Outside Diameter (in)	3.296 in
Overall Length (in)	1.98075 in
Bore Type	Bushed Bore
Number of Strands/Width	2
Hub Diameter (in)	2.494 in
Pitch Type	Single
Hardened Teeth	Yes

General Specifications

UPC	662289198351
Weight	1.43 LB
Packaged Length	4.40 IN
Packaged Width	4.20 IN
Packaged Height	1.70 IN
HTC	8483.90.1050
Country of Origin	China
