• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Pitch (in)	1 in
Product Type	Bushed Roller Chain Sprocket
Max Bore (in)	3.75 in
Number of Teeth	23
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Material	Steel, Hardened Teeth
Min Bore (in)	1.125 in
Bushing Used	Split Taper
Pitch Diameter (in)	7.3439 in
Bore Type	Bushed Bore
Overall Length (in)	3.141375 in
Outside Diameter (in)	7.876 in
Number of Strands/Width	2
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Maximum Bore (mm)	95 mm
Minimum Bore (mm)	28 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289189717
Weight	12.50 LB
Packaged Length	7.88 IN
Packaged Width	7.88 IN
Packaged Height	2.25 IN
HTC	8483.90.1050
Country of Origin	China
