• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Product Type	Bushed Roller Chain Sprocket
Number of Teeth	17
Max Bore (in)	2.6875 in
Min Bore (in)	0.75 in
Chain Pitch (in)	1 in
Pitch Diameter (in)	5.4422 in
Bushing Used	Split Taper
Material	Steel, Hardened Teeth
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Overall Length (in)	2.78125 in
Outside Diameter (in)	5.95 in
Bore Type	Bushed Bore
Number of Strands/Width	2
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Pitch Type	Single

General Specifications

UPC	662289119622
Weight	6.20 LB
Packaged Length	6.30 IN
Packaged Width	6.00 IN
Packaged Height	2.30 IN
HTC	8483.90.1050
Country of Origin	China
