• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Number of Teeth	16
Material	Steel
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Chain Pitch (in)	1 in
Max Bore (in)	2.6875 in
Product Type	Bushed Roller Chain Sprocket
Bushing Used	Split Taper
Min Bore (in)	0.75 in
Pitch Diameter (in)	5.1258 in
Overall Length (in)	2.78125 in
Outside Diameter (in)	5.627 in
Bore Type	Bushed Bore
Number of Strands/Width	2
Tooth Width (in)	0.557 in
Length Through Bore (in)	2.5 in
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Maximum Bore (mm)	65 mm
Minimum Bore (mm)	18 mm
Hardened Teeth	No
Hub Projection (in)	0.844 in
Pitch Type	Single
Overall Width (in)	2.78125 in

General Specifications

UPC	662289219605
Weight	5.07 LB
Packaged Length	6.10 IN
Packaged Width	5.90 IN
Packaged Height	2.50 IN
HTC	8483.90.1050
Country of Origin	China
