• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Pitch (in)	0.75 in
Product Type	Bushed Roller Chain Sprocket
Material	Steel
Chain Used	No. 60, 3/4 in. Pitch ANSI Chain
Pitch Diameter (in)	10.752 in
Number of Teeth	45
Max Bore (in)	3.75 in
Bushing Used	Split Taper
Min Bore (in)	1.125 in
Bore Type	Bushed Bore
Outside Diameter (in)	11.176 in
Overall Length (in)	3.141375 in
Number of Strands/Width	2
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Minimum Bore (mm)	28 mm
Maximum Bore (mm)	95 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289149506
Weight	30.15 LB
Packaged Length	12.30 IN
Packaged Width	12.40 IN
Packaged Height	2.40 IN
HTC	8483.90.1050
Country of Origin	China
