• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Number of Teeth	24
Min Bore (in)	0.75 in
Pitch Diameter (in)	5.746 in
Max Bore (in)	2.6875 in
Bushing Used	Split Taper
Chain Pitch (in)	0.75 in
Chain Used	No. 60, 3/4 in. Pitch ANSI Chain
Product Type	Bushed Roller Chain Sprocket
Material	Steel, Hardened Teeth
Overall Length (in)	2.828125 in
Outside Diameter (in)	6.147 in
Bore Type	Bushed Bore
Number of Strands/Width	2
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Maximum Bore (mm)	65 mm
Minimum Bore (mm)	18 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289309443
Weight	7.21 LB
Packaged Length	6.40 IN
Packaged Width	6.30 IN
Packaged Height	2.20 IN
HTC	8483.90.1050
Country of Origin	China
