• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Bushing Used	Split Taper
Pitch Diameter (in)	11.9421 in
Max Bore (in)	2.6875 in
Number of Teeth	60
Material	Steel
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Product Type	Bushed Roller Chain Sprocket
Min Bore (in)	0.75 in
Chain Pitch (in)	0.625 in
Outside Diameter (in)	12.301 in
Bore Type	Bushed Bore
Overall Length (in)	2.828125 in
Number of Strands/Width	2
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Maximum Bore (mm)	65 mm
Minimum Bore (mm)	18 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289259236
Weight	30.45 LB
Packaged Length	12.75 IN
Packaged Width	1.75 IN
Packaged Height	12.75 IN
HTC	8483.90.1050
Country of Origin	China
