• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Pitch Diameter (in)	4.987 in
Number of Teeth	25
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Min Bore (in)	0.75 in
Bushing Used	Split Taper
Chain Pitch (in)	0.625 in
Max Bore (in)	2.6875 in
Product Type	Bushed Roller Chain Sprocket
Material	Steel, Hardened Teeth
Bore Type	Bushed Bore
Outside Diameter (in)	5.322 in
Overall Length (in)	2.828125 in
Number of Strands/Width	2
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289229123
Weight	4.26 LB
Packaged Length	6.10 IN
Packaged Width	6.00 IN
Packaged Height	2.00 IN
HTC	8483.90.1050
Country of Origin	China
