• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Min Bore (in)	0.5 in
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Product Type	Bushed Roller Chain Sprocket
Max Bore (in)	1.75 in
Number of Teeth	20
Material	Steel, Hardened Teeth
Chain Pitch (in)	0.625 in
Pitch Diameter (in)	3.995 in
Bushing Used	Split Taper
Overall Length (in)	2.142725 in
Bore Type	Bushed Bore
Outside Diameter (in)	4.321 in
Number of Strands/Width	2
Hub Diameter (in)	3 in
Maximum Bore (in)	1.75 in
Minimum Bore (mm)	14 mm
Maximum Bore (mm)	42 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289169092
Weight	2.58 LB
Packaged Length	6.40 IN
Packaged Width	6.20 IN
Packaged Height	1.50 IN
HTC	8483.90.1050
Country of Origin	China
