• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Max Bore (in)	1.75 in
Chain Pitch (in)	0.625 in
Pitch Diameter (in)	3.797 in
Material	Steel, Hardened Teeth
Min Bore (in)	0.5 in
Number of Teeth	19
Product Type	Bushed Roller Chain Sprocket
Bushing Used	Split Taper
Bore Type	Bushed Bore
Overall Length (in)	2.142725 in
Hub Diameter (in)	3 in
Hub Type	Bushed
Tooth Width (in)	0.332 in
Sprocket Material	Steel, Hardened Teeth
Length Through Bore (in)	1.9375 in
Outside Diameter (in)	4.12 in
Number of Strands/Width	2
Maximum Bore (in)	1.75 in
Minimum Bore (mm)	14 mm
Maximum Bore (mm)	42 mm
Number of Hubs	1
Pitch Type	Single
Min Bushing Bore (in)	0.5 in
Max Bushing Bore (in)	1.75 in

General Specifications

UPC	662289239061
Weight	2.26 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.31 IN
HTC	8483.90.1050
Country of Origin	China
