• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Material	Steel, Hardened Teeth
Bushing Used	Split Taper
Product Type	Bushed Roller Chain Sprocket
Pitch Diameter (in)	2.809 in
Max Bore (in)	1.5 in
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Number of Teeth	14
Chain Pitch (in)	0.625 in
Min Bore (in)	0.375 in
Outside Diameter (in)	3.113 in
Overall Length (in)	2.47425 in
Bore Type	Bushed Bore
Number of Strands/Width	2
Hub Diameter (in)	2.494 in
Maximum Bore (in)	1.5 in
Maximum Bore (mm)	38 mm
Minimum Bore (mm)	10 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289179008
Weight	1.28 LB
Packaged Length	3.70 IN
Packaged Width	3.40 IN
Packaged Height	2.10 IN
HTC	8483.90.1050
Country of Origin	China
