• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Max Bore (in)	2.6875 in
Chain Pitch (in)	0.5 in
Material	Steel, Hardened Teeth
Min Bore (in)	0.75 in
Number of Teeth	30
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Pitch Diameter (in)	4.783 in
Product Type	Bushed Roller Chain Sprocket
Bushing Used	Split Taper
Outside Diameter (in)	5.057 in
Bore Type	Bushed Bore
Overall Length (in)	2.792375 in
Number of Strands/Width	2
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289278947
Weight	3.68 LB
Packaged Length	5.20 IN
Packaged Width	5.00 IN
Packaged Height	2.10 IN
HTC	8483.90.1050
Country of Origin	China
