• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Pitch Diameter (in)	3.672 in
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Chain Pitch (in)	0.5 in
Number of Teeth	23
Material	Steel, Hardened Teeth
Product Type	Bushed Roller Chain Sprocket
Max Bore (in)	1.75 in
Bushing Used	Split Taper
Min Bore (in)	0.5 in
Overall Length (in)	2.142725 in
Bore Type	Bushed Bore
Outside Diameter (in)	3.938 in
Number of Strands/Width	2
Hub Diameter (in)	3 in
Maximum Bore (in)	1.75 in
Maximum Bore (mm)	42 mm
Minimum Bore (mm)	14 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289540624
Weight	2.03 LB
Packaged Length	4.30 IN
Packaged Width	4.20 IN
Packaged Height	1.60 IN
HTC	8483.90.1050
Country of Origin	China
