• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Pitch Diameter (in)	3.355 in
Min Bore (in)	0.5 in
Bushing Used	Split Taper
Max Bore (in)	1.75 in
Chain Pitch (in)	0.5 in
Number of Teeth	21
Product Type	Bushed Roller Chain Sprocket
Material	Steel, Hardened Teeth
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Overall Length (in)	2.143225 in
Bore Type	Bushed Bore
Outside Diameter (in)	3.617 in
Number of Strands/Width	2
Hub Diameter (in)	3 in
Maximum Bore (in)	1.75 in
Minimum Bore (mm)	14 mm
Maximum Bore (mm)	42 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289510603
Weight	1.92 LB
Packaged Length	4.56 IN
Packaged Width	4.56 IN
Packaged Height	1.56 IN
HTC	8483.90.1050
Country of Origin	China
