• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Made with Minimum bore, no keyseat or setscrew. This can be bored to size with keyseat and setscrew for a reasonable extra charge.
• Maximum Bore Shown will accommodate standard keyways and setscrews over keyway. Slightly larger bores are possible with no keyway, shallow keyway or setscrew at angle to keyway.

Technical Specifications

Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Chain Pitch (in)	0.5 in
Material	Hardened Steel
Number of Teeth	32
Product Type	Type "B" Minimum Bore Double Sprocket
Max Bore (in)	2.25 in
Bore Type	Minimum Plain Bore
Outside Diameter (in)	5.38 in
Pitch Diameter (in)	5.101 in
Bore Diameter (in)	0.875 in
Number of Strands/Width	2
Hub Type	Type DB
Tooth Width (in)	0.275 in
Hub Diameter (in)	3.25 in
Length Through Bore (in)	1.625 in
Maximum Bore (in)	2.25 in
Maximum Bore (mm)	57 mm
Minimum Bore (mm)	23 mm
Hardened Teeth	With Hardened Teeth
Pitch Type	Double
Hub Projection (in)	0.78125 in
Number of Hubs	1

General Specifications

UPC	662289262021
Weight	6.08 LB
Packaged Length	6.10 IN
Packaged Width	6.20 IN
Packaged Height	2.00 IN
HTC	8483.90.1050
Country of Origin	China
