• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Used	No. 100, 1-1/4 in. Pitch ANSI Chain
Max Bore (in)	2.6875 in
Chain Pitch (in)	1.25 in
Material	Steel, Hardened Teeth
Number of Teeth	14
Bushing Used	Split Taper
Product Type	Bushed Roller Chain Sprocket
Pitch Diameter (in)	5.6174 in
Min Bore (in)	0.75 in
Outside Diameter (in)	6.227 in
Overall Length (in)	3.15625 in
Bore Type	Bushed Bore
Number of Strands/Width	2
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Pitch Type	Single

General Specifications

UPC	662289249886
Weight	8.36 LB
Packaged Length	8.40 IN
Packaged Width	8.60 IN
Packaged Height	2.40 IN
HTC	8483.90.1050
Country of Origin	China
