• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Product Type	Bushed Roller Chain Sprocket
Number of Teeth	50
Material	Steel
Chain Pitch (in)	1 in
Bushing Used	Split Taper
Min Bore (in)	1.125 in
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Max Bore (in)	3.75 in
Pitch Diameter (in)	15.926 in
Outside Diameter (in)	16.495 in
Overall Length (in)	3.15625 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Minimum Bore (mm)	28 mm
Maximum Bore (mm)	95 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289277070
Weight	35.78 LB
Packaged Length	19.30 IN
Packaged Width	19.60 IN
Packaged Height	2.10 IN
HTC	8483.90.1050
Country of Origin	United States of America
