• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Bushing Used	Split Taper
Min Bore (in)	1.125 in
Max Bore (in)	3.75 in
Product Type	Bushed Roller Chain Sprocket
Material	Steel
Number of Teeth	40
Chain Pitch (in)	1 in
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Pitch Diameter (in)	12.745 in
Overall Length (in)	3.15625 in
Outside Diameter (in)	13.306 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Maximum Bore (mm)	95 mm
Minimum Bore (mm)	28 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289246977
Weight	23.94 LB
Packaged Length	13.90 IN
Packaged Width	14.10 IN
Packaged Height	2.40 IN
HTC	8483.90.1050
Country of Origin	China
