• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Used	No. 80, 1 in. Pitch ANSI Chain
Max Bore (in)	2.6875 in
Bushing Used	Split Taper
Product Type	Bushed Roller Chain Sprocket
Material	Steel
Min Bore (in)	0.75 in
Number of Teeth	48
Chain Pitch (in)	1 in
Pitch Diameter (in)	15.29 in
Outside Diameter (in)	15.857 in
Bore Type	Bushed Bore
Overall Length (in)	2.828125 in
Number of Strands/Width	1
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289297016
Weight	31.10 LB
Packaged Length	15.86 IN
Packaged Width	15.86 IN
Packaged Height	2.78 IN
HTC	8483.90.1050
Country of Origin	China
