• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Material	Steel
Product Type	Bushed Roller Chain Sprocket
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Bushing Used	Split Taper
Max Bore (in)	2.6875 in
Chain Pitch (in)	1 in
Number of Teeth	38
Min Bore (in)	0.75 in
Pitch Diameter (in)	12.11 in
Bore Type	Bushed Bore
Overall Length (in)	2.828125 in
Outside Diameter (in)	12.668 in
Number of Strands/Width	1
Hub Diameter (in)	4.125 in
Tooth Width (in)	0.575 in
Length Through Bore (in)	2.5 in
Maximum Bore (in)	2.6875 in
Maximum Bore (mm)	65 mm
Minimum Bore (mm)	18 mm
Pitch Type	Single
Hub Projection (in)	2.015 in
Number of Hubs	1
Hardened Teeth	No
Overall Width (in)	2.828125 in

General Specifications

UPC	662289306893
Weight	20.60 LB
Packaged Length	13.80 IN
Packaged Width	13.40 IN
Packaged Height	2.50 IN
HTC	8483.90.1050
Country of Origin	China
