• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Used	No. 80, 1 in. Pitch ANSI Chain
Number of Teeth	34
Pitch Diameter (in)	10.838 in
Material	Steel
Max Bore (in)	2.6875 in
Chain Pitch (in)	1 in
Bushing Used	Split Taper
Min Bore (in)	0.75 in
Product Type	Bushed Roller Chain Sprocket
Outside Diameter (in)	11.392 in
Bore Type	Bushed Bore
Overall Length (in)	2.828125 in
Number of Strands/Width	1
Length Through Bore (in)	2.5 in
Hub Diameter (in)	4.125 in
Tooth Width (in)	0.575 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Hub Projection (in)	2.015 in
Pitch Type	Single
Number of Hubs	1
Hardened Teeth	Yes
Overall Width (in)	2.828125 in

General Specifications

UPC	662289156825
Weight	15.50 LB
Packaged Length	11.38 IN
Packaged Width	11.38 IN
Packaged Height	1.75 IN
HTC	8483.90.1050
Country of Origin	China
