• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Made with Minimum bore, no keyseat or setscrew. This can be bored to size with keyseat and setscrew for a reasonable extra charge.
• Maximum Bore Shown will accommodate standard keyways and setscrews over keyway. Slightly larger bores are possible with no keyway, shallow keyway or setscrew at angle to keyway.

Technical Specifications

Bore Type	Minimum Plain Bore
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Material	Steel
Hub Type	Type B
Bore Diameter (in)	1 in
Number of Teeth	25
Length Through Bore (in)	1.75 in
Chain Pitch (in)	1 in
Maximum Bore (in)	2.125 in
Maximum Bore (mm)	53 mm
Minimum Bore (mm)	26 mm
Number of Hubs	1

General Specifications

UPC	662289220373
Weight	12.34 LB
Packaged Length	10.50 IN
Packaged Width	10.40 IN
Packaged Height	2.70 IN
HTC	8483.90.1050
Country of Origin	China
