• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Product Type	Type "A" Plate Sprocket
Material	Steel
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Number of Teeth	72
Chain Pitch (in)	1 in
Outside Diameter (in)	23.504 in
Bore Type	Minimum Plain Bore
Pitch Diameter (in)	22.925586 in
Number of Strands/Width	1
Bore Diameter (in)	1.5 in
Tooth Width (in)	0.575 in
Hub Type	Type A
Length Through Bore (in)	0.575 in
Maximum Bore (in)	1 in
Maximum Bore (mm)	0 mm
Minimum Bore (mm)	0 mm
Hardened Teeth	Non-Hardened Teeth
Pitch Type	Single
Number of Hubs	0

General Specifications

UPC	662289122639
Weight	63.00 LB
Packaged Length	0.58 IN
Packaged Width	23.46 IN
Packaged Height	23.46 IN
HTC	8483.90.1050
Country of Origin	China
