• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Number of Teeth	48
Product Type	Type "A" Plate Sprocket
Material	Steel
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Chain Pitch (in)	1 in
Sprocket Material	Steel
Tooth Width (in)	0.575 in
Outside Diameter (in)	15.857 in
Bore Type	Minimum Plain Bore
Hub Type	Type A
Overall Length (in)	0.575 in
Length Through Bore (in)	0.575 in
Chain Number	No. 80, 1 in. Pitch ANSI Chain
Pitch Diameter (in)	15.289788 in
Bore Diameter (in)	1.25 in
Number of Strands/Width	1
Maximum Bore (in)	1 in
Maximum Bore (mm)	0 mm
Minimum Bore (mm)	0 mm
Hardened Teeth	Non-Hardened Teeth
Number of Hubs	0

General Specifications

UPC	662289318094
Weight	29.12 LB
Packaged Length	15.00 IN
Packaged Width	16.10 IN
Packaged Height	1.80 IN
HTC	8483.90.1050
Country of Origin	China
