• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Pitch (in)	1 in
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Product Type	Type "A" Plate Sprocket
Material	Steel
Number of Teeth	45
Outside Diameter (in)	14.901 in
Bore Type	Minimum Plain Bore
Pitch Diameter (in)	14.335587 in
Bore Diameter (in)	1.25 in
Number of Strands/Width	1
Length Through Bore (in)	0.575 in
Hub Type	Type A
Maximum Bore (in)	1 in
Minimum Bore (mm)	0 mm
Maximum Bore (mm)	0 mm
Number of Hubs	0
Hardened Teeth	Non-Hardened Teeth

General Specifications

UPC	662289292547
Weight	25.43 LB
Packaged Length	15.10 IN
Packaged Width	15.20 IN
Packaged Height	1.10 IN
HTC	8483.90.1050
Country of Origin	China
