• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Used	No. 80, 1 in. Pitch ANSI Chain
Material	Steel
Product Type	Type "A" Plate Sprocket
Chain Pitch (in)	1 in
Number of Teeth	36
Outside Diameter (in)	12.03 in
Bore Type	Minimum Plain Bore
Pitch Diameter (in)	11.473713 in
Bore Diameter (in)	1.1875 in
Number of Strands/Width	1
Hub Type	Type A
Length Through Bore (in)	0.575 in
Maximum Bore (in)	1 in
Maximum Bore (mm)	0 mm
Minimum Bore (mm)	0 mm
Hardened Teeth	With Hardened Teeth
Number of Hubs	0

General Specifications

UPC	662289122486
Weight	16.13 LB
Packaged Length	12.50 IN
Packaged Width	12.10 IN
Packaged Height	1.30 IN
HTC	8483.90.1050
Country of Origin	China
