• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Used	No. 80, 1 in. Pitch ANSI Chain
Material	Steel
Number of Teeth	35
Product Type	Type "A" Plate Sprocket
Chain Pitch (in)	1 in
Length Through Bore (in)	0.575 in
Sprocket Material	Steel, Hardened Teeth
Overall Length (in)	0.575 in
Outside Diameter (in)	11.711 in
Hub Type	Type A
Tooth Width (in)	0.575 in
Bore Type	Minimum Plain Bore
Chain Number	No. 80, 1 in. Pitch ANSI Chain
Pitch Diameter (in)	11.15582 in
Number of Strands/Width	1
Bore Diameter (in)	1.1875 in
Maximum Bore (in)	1 in
Maximum Bore (mm)	0 mm
Minimum Bore (mm)	0 mm
Number of Hubs	0
Hardened Teeth	With Hardened Teeth

General Specifications

UPC	662289202454
Weight	15.36 LB
Packaged Length	12.40 IN
Packaged Width	12.40 IN
Packaged Height	1.00 IN
HTC	8483.90.1050
Country of Origin	China
