• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Pitch (in)	1 in
Product Type	Type "A" Plate Sprocket
Number of Teeth	28
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Material	Steel
Bore Type	Minimum Plain Bore
Outside Diameter (in)	9.475 in
Pitch Diameter (in)	8.931404 in
Bore Diameter (in)	1.1875 in
Number of Strands/Width	1
Hub Type	Type A
Length Through Bore (in)	0.575 in
Maximum Bore (in)	1 in
Maximum Bore (mm)	0 mm
Minimum Bore (mm)	0 mm
Hardened Teeth	With Hardened Teeth
Number of Hubs	0

General Specifications

UPC	662289302413
Weight	9.66 LB
Packaged Length	10.50 IN
Packaged Width	10.50 IN
Packaged Height	1.30 IN
HTC	8483.90.1050
Country of Origin	China
