• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Used	No. 80, 1 in. Pitch ANSI Chain
Number of Teeth	26
Material	Steel
Chain Pitch (in)	1 in
Product Type	Type "A" Plate Sprocket
Tooth Width (in)	0.575 in
Length Through Bore (in)	0.575 in
Overall Length (in)	0.575 in
Sprocket Material	Steel, Hardened Teeth
Outside Diameter (in)	8.836 in
Bore Type	Minimum Plain Bore
Hub Type	Type A
Chain Number	No. 80, 1 in. Pitch ANSI Chain
Pitch Diameter (in)	8.29623 in
Number of Strands/Width	1
Bore Diameter (in)	1.1875 in
Maximum Bore (in)	1 in
Maximum Bore (mm)	0 mm
Minimum Bore (mm)	0 mm
Hardened Teeth	With Hardened Teeth
Number of Hubs	0
Pitch Type	Single

General Specifications

UPC	662289262366
Weight	8.21 LB
Packaged Length	10.00 IN
Packaged Width	9.60 IN
Packaged Height	0.70 IN
HTC	8483.90.1050
Country of Origin	China
