• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Pitch (in)	1 in
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Material	Steel
Number of Teeth	20
Product Type	Type "A" Plate Sprocket
Outside Diameter (in)	6.914 in
Bore Type	Minimum Plain Bore
Pitch Diameter (in)	6.392453 in
Bore Diameter (in)	0.9375 in
Number of Strands/Width	1
Hub Type	Type A
Length Through Bore (in)	0.575 in
Maximum Bore (in)	0.75 in
Maximum Bore (mm)	0 mm
Minimum Bore (mm)	0 mm
Number of Hubs	0
Hardened Teeth	With Hardened Teeth

General Specifications

UPC	662289222322
Weight	4.82 LB
Packaged Length	7.30 IN
Packaged Width	6.80 IN
Packaged Height	0.80 IN
HTC	8483.90.1050
Country of Origin	China
