• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Pitch (in)	1 in
Product Type	Type "A" Plate Sprocket
Material	Steel
Number of Teeth	112
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Outside Diameter (in)	36.241 in
Bore Type	Minimum Plain Bore
Pitch Diameter (in)	35.655383 in
Bore Diameter (in)	1.5 in
Number of Strands/Width	1
Length Through Bore (in)	0.575 in
Hub Type	Type A
Maximum Bore (in)	1.4375 in
Maximum Bore (mm)	0 mm
Minimum Bore (mm)	0 mm
Number of Hubs	0
Hardened Teeth	Non-Hardened Teeth

General Specifications

UPC	662289318100
Weight	153.00 LB
Packaged Length	0.58 IN
Packaged Width	36.20 IN
Packaged Height	36.20 IN
HTC	8483.90.1050
Country of Origin	China
