• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Used	No. 60, 3/4 in. Pitch ANSI Chain
Chain Pitch (in)	0.75 in
Product Type	Type "A" Plate Sprocket
Material	Steel
Number of Teeth	72
Outside Diameter (in)	17.628 in
Overall Length (in)	0.459 in
Sprocket Material	Steel
Length Through Bore (in)	0.459 in
Tooth Width (in)	0.459 in
Hub Type	Type A
Bore Type	Minimum Plain Bore
Chain Number	No. 60, 3/4 in. Pitch ANSI Chain
Pitch Diameter (in)	17.194189 in
Bore Diameter (in)	1.25 in
Number of Strands/Width	1
Maximum Bore (in)	3.125 in
Minimum Bore (mm)	26 mm
Maximum Bore (mm)	79 mm
Number of Hubs	0
Pitch Type	Single
Hardened Teeth	Non-Hardened Teeth

General Specifications

UPC	662289212217
Weight	29.69 LB
Packaged Length	15.60 IN
Packaged Width	16.70 IN
Packaged Height	1.30 IN
HTC	8483.90.1050
Country of Origin	China
