• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Product Type	Type "A" Plate Sprocket
Number of Teeth	48
Material	Steel
Chain Pitch (in)	0.75 in
Chain Used	No. 60, 3/4 in. Pitch ANSI Chain
Bore Type	Minimum Plain Bore
Outside Diameter (in)	11.893 in
Pitch Diameter (in)	11.467341 in
Number of Strands/Width	1
Bore Diameter (in)	1 in
Length Through Bore (in)	0.459 in
Hub Type	Type A
Maximum Bore (in)	2.125 in
Minimum Bore (mm)	26 mm
Maximum Bore (mm)	53 mm
Number of Hubs	0
Hardened Teeth	Non-Hardened Teeth

General Specifications

UPC	662289162062
Weight	13.01 LB
Packaged Length	11.80 IN
Packaged Width	12.00 IN
Packaged Height	0.90 IN
HTC	8483.90.1050
Country of Origin	China
