• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Material	Steel
Chain Used	No. 60, 3/4 in. Pitch ANSI Chain
Product Type	Type "A" Plate Sprocket
Number of Teeth	26
Chain Pitch (in)	0.75 in
Sprocket Material	Steel, Hardened Teeth
Bore Type	Minimum Plain Bore
Overall Length (in)	0.459 in
Tooth Width (in)	0.459 in
Hub Type	Type A
Length Through Bore (in)	0.459 in
Outside Diameter (in)	6.627 in
Chain Number	No. 60, 3/4 in. Pitch ANSI Chain
Pitch Diameter (in)	6.222172 in
Number of Strands/Width	1
Bore Diameter (in)	0.75 in
Maximum Bore (in)	2.75 in
Maximum Bore (mm)	69 mm
Minimum Bore (mm)	20 mm
Hardened Teeth	With Hardened Teeth
Number of Hubs	0

General Specifications

UPC	662289101948
Weight	3.78 LB
Packaged Length	6.60 IN
Packaged Width	7.20 IN
Packaged Height	0.60 IN
HTC	8483.90.1050
Country of Origin	China
