• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Product Type	Type "A" Plate Sprocket
Number of Teeth	20
Material	Steel
Chain Pitch (in)	0.75 in
Chain Used	No. 60, 3/4 in. Pitch ANSI Chain
Bore Type	Minimum Plain Bore
Outside Diameter (in)	5.185 in
Pitch Diameter (in)	4.79434 in
Bore Diameter (in)	0.75 in
Number of Strands/Width	1
Hub Type	Type A
Length Through Bore (in)	0.459 in
Maximum Bore (in)	2.625 in
Maximum Bore (mm)	66 mm
Minimum Bore (mm)	20 mm
Number of Hubs	0
Hardened Teeth	With Hardened Teeth

General Specifications

UPC	662289161836
Weight	2.04 LB
Packaged Length	9.25 IN
Packaged Width	9.25 IN
Packaged Height	3.75 IN
HTC	8483.90.1050
Country of Origin	China
