• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Pitch (in)	0.625 in
Max Bore (in)	2.6875 in
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Number of Teeth	60
Product Type	Bushed Roller Chain Sprocket
Bushing Used	Split Taper
Pitch Diameter (in)	11.942 in
Min Bore (in)	0.75 in
Material	Steel
Overall Length (in)	2.828125 in
Outside Diameter (in)	12.301 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289285815
Weight	13.96 LB
Packaged Length	12.50 IN
Packaged Width	12.70 IN
Packaged Height	2.90 IN
HTC	8483.90.1050
Country of Origin	China
