• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Min Bore (in)	0.5 in
Number of Teeth	33
Material	Steel
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Chain Pitch (in)	0.625 in
Bushing Used	Split Taper
Product Type	Bushed Roller Chain Sprocket
Pitch Diameter (in)	6.575 in
Max Bore (in)	1.75 in
Sprocket Material	Steel, Hardened Teeth
Tooth Width (in)	0.343 in
Overall Length (in)	2.221225 in
Bore Type	Bushed Bore
Outside Diameter (in)	6.92 in
Hub Type	Bushed
Hub Diameter (in)	3 in
Length Through Bore (in)	2.9375 in
Number of Strands/Width	1
Maximum Bore (in)	1.75 in
Maximum Bore (mm)	42 mm
Minimum Bore (mm)	14 mm
Pitch Type	Single
Number of Hubs	1
Max Bushing Bore (in)	1.75 in
Min Bushing Bore (in)	0.5 in

General Specifications

UPC	662289265640
Weight	4.06 LB
Packaged Length	7.06 IN
Packaged Width	7.06 IN
Packaged Height	1.56 IN
HTC	8483.90.1050
Country of Origin	China
