• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Made with Minimum bore, no keyseat or setscrew. This can be bored to size with keyseat and setscrew for a reasonable extra charge.
• Maximum Bore Shown will accommodate standard keyways and setscrews over keyway. Slightly larger bores are possible with no keyway, shallow keyway or setscrew at angle to keyway.

Technical Specifications

Material	Steel
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Number of Teeth	26
Chain Pitch (in)	0.625 in
Product Type	Type "B" Minimum Bore Sprocket
Bore Type	Minimum Plain Bore
Max Bore (in)	2 in
Outside Diameter (in)	5.52 in
Pitch Diameter (in)	5.185 in
Bore Diameter (in)	0.75 in
Number of Strands/Width	1
Hub Type	Type B
Length Through Bore (in)	1.25 in
Hub Diameter (in)	3 in
Maximum Bore (in)	2.25 in
Minimum Bore (mm)	20 mm
Maximum Bore (mm)	57 mm
Hub Projection (in)	0.90625 in
Number of Hubs	1

General Specifications

UPC	662289319442
Weight	3.55 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.31 IN
HTC	8483.90.1050
Country of Origin	China
