• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Made with Minimum bore, no keyseat or setscrew. This can be bored to size with keyseat and setscrew for a reasonable extra charge.
• Maximum Bore Shown will accommodate standard keyways and setscrews over keyway. Slightly larger bores are possible with no keyway, shallow keyway or setscrew at angle to keyway.
• Made with Minimum bore, no keyseat or setscrew. This can be bored to size with keyseat and setscrew for a reasonable extra charge.

Technical Specifications

Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Number of Teeth	11
Chain Pitch (in)	0.625 in
Bore Type	Minimum Plain Bore
Hub Diameter (in)	1.75 in
Tooth Width (in)	0.343 in
Max Bore (in)	1 in
Overall Length (in)	1 in
Length Through Bore (in)	1 in
Sprocket Material	Steel, Hardened Teeth
Outside Diameter (in)	2.5 in
Hub Type	Type B
Min Bore (in)	0.625 in
Pitch Diameter (in)	2.219 in
Number of Strands/Width	1
Bore Diameter (in)	0.625 in
Material	Steel, Hardened Teeth
Maximum Bore (in)	1 in
Minimum Bore (mm)	16 mm
Maximum Bore (mm)	25 mm
Number of Hubs	1

General Specifications

UPC	662289149452
Weight	0.67 LB
Packaged Length	2.90 IN
Packaged Width	2.80 IN
Packaged Height	1.40 IN
HTC	8483.90.1050
Country of Origin	China
