• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Number of Teeth	72
Material	Steel
Chain Pitch (in)	0.625 in
Product Type	Type "A" Plate Sprocket
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Bore Type	Minimum Plain Bore
Outside Diameter (in)	14.69 in
Pitch Diameter (in)	14.328491 in
Bore Diameter (in)	0.9375 in
Number of Strands/Width	1
Tooth Width (in)	0.343 in
Hub Type	Type A
Length Through Bore (in)	0.343 in
Maximum Bore (in)	2.5 in
Maximum Bore (mm)	63 mm
Minimum Bore (mm)	26 mm
Number of Hubs	0
Pitch Type	Single
Hardened Teeth	Non-Hardened Teeth

General Specifications

UPC	662289281701
Weight	15.50 LB
Packaged Length	16.30 IN
Packaged Width	16.50 IN
Packaged Height	1.40 IN
HTC	8483.90.1050
Country of Origin	China
